Specifications
| Weight | 115 g (excluding bracket) |
| Dimensions | 91×54×60 mm (L×W×H, excluding bracket) |
| Max Power | Spotlight: 40 W Floodlight: 18 W Both On: 48 W |
| Illuminance | Spotlight: 11.2±0.5 lux @ 100 meters Floodlight: 2.7±0.2 lux @ 100 meters |
| Effective Illumination Angle | Spotlight: 14.5° (10% center illuminance) Floodlight: 23° (10% center illuminance) |
| Effective Illumination Area | Spotlight: 500 square meters @ 100 meters (10% center illuminance) Floodlight: 1,300 square meters @ 100 meters (10% center illuminance) |
| Operating Mode | Always-On Mode: Spotlight, Floodlight, Both On, and Auto (automatically switches lighting modes based on the zoom level) Strobe Mode: Slow, Fast |
| Gimbal Mechanical Range | Tilt: -135° to +135° |
| Gimbal Controllable Range | Tilt: -90° to +90° |
| Gimbal Max Control Speed (tilt) | 120°/s |
| Gimbal Alignment Accuracy | ±0.1° |
| Operating Temperature | -40° to 50° C (-40° to 122° F) |
| Ingress Protection Rating | IP55 |
| Mounting | Mounted on the right side of the aircraft using the Matrice 5TD Accessory Mount. Make sure to tighten the mounting screws during installation. |
