KEY FEATURES

  • DJI M350RTK is used as the flight bearing platform.
  • Ultra-high speed spectral scanning imaging device with high signal-to-noise ratio provides high stability spectral image acquisition.
  • The self-developed image processing algorithm with high efficiency and low power consumption can greatly prolong the flight time and reduce the power consumption of the system.
  • Through real-time measurement of spectral image information of plants, water bodies, soil and other ground objects, application and precision agriculture, crop growth and yield assessment, forest pest monitoring and fire prevention monitoring, coastline and Marine environment monitoring, lake and watershed environmental monitoring and other applications.
  • Compact system design, imaging spectrometer host spectral resolution up to 2.5nm.
  • Compact system design, imaging spectrometer host spectral resolution up to 2.5nm.
    The whole machine consists of: high stability head, hyperspectral imager, embedded data acquisition, processing and storage unit, wireless image transmission system, GPS-RTK navigation system, ground receiving workstation, ground control system, reflectivity calibration board.



PARAMETERS

Spectroscopic MethodTransmission Grating
Spectral Range900-1700nm
Spectral Band1024
Spectral Resolution (FWHM)6.5 nm
Slit Width25um
Transmission Efficiency> 60%
Stray Light< 0.5%
Number of Spatial Pixels1280
Pixel Size5 um
Imaging SpeedFull band 70Hz, maximum 1800Hz
ProbeInGaAs
Signal-To-Noise Ratio600/1
ExportationStart
Camera InterfaceC-Mount
AttachmentLens, USB Cable, Power Supply
ROIMultiple Regions
Built-In Processing UnitWindows Operating System, 8GB
of RAM 512GB SSD and Camera
Integrated Design (optional 1TB)
Heat Dissipation ModeInternal air cooling heat dissipation
Mode of OperationEasy to operate, no need for professional drone operation Hand control, can achieve single operation.
Observation ModeReal-time observation of aircraft sampling sites, hyperspectral images and spectral data by
ground stations.
Correction ModeRadiometric correction, reflectivity correction, and area correction support batch processing
Data FormatCompatible with spe, hdr, and scp formats
Camera SizeLess than 135*82*100 mm (L * W * H)
(Including lens and built-in embedded data acquisition and processing unit, excluding head)
Less than 190*129*100 mm (L * W * H)
(Including lens and built-in embedded data acquisition and processing unit, including head)
Camera Weight≤ 740g (including lens and built-in embedded data acquisition and processing unit, excluding PTZ)
≤ 1085g (including lens and built-in embedded data acquisition and processing unit, including head)
AttachmentsReflectance Calibration Board
Lens Focal Length25mm
Camera Scene>25°
Application
Software
FIGSPEC UAV real-time flight control software,FIGSPEC Merge puzzle software,
FIGSPEC Studion image analysis software
