Hi-Target V200 Rover + iRTK5 Base (Full Set)

Higher Accuracy and Precision

Equipped with the High-Performance Patch Antenna, enhances the low elevation angle tracking capabilities and keeps it maintaining a high gain for higher elevation satellites while tracking low-elevation satellites.

More Stability

Hi-Target Hi-Fix enables continuous connectivity and quality results even if you lose the signal while using the RTK base station or VRS network under extreme circumstances.

More Portability

Equipped with an ultra-light EPP material instrument case of a high anti-strong impact, shock and impact resistance and a centering rod that can be contracted to 1.25 m, making it durable and portable in the fieldwork.

Greater Flexibility

It can bring accurate and reliable results and boost efficient fieldwork with self-developed built-in IMU and core algorithm.

iHand55 Controller

The iHand55 Handheld Controller is a professional field controller with a big vision. Adopting a full-keyboard design, iHand55 supports the fast charge. The updated screen is readable in direct sunlight. More features of the latest Hi-Survey Road Software contribute to achieving high intelligence. Keeping robust and reliable in fieldwork under any conditions, iHand55 is a perfect choice for your survey work.

- 5.5”sunlight readable display capacitive touch screen for fingers or stylus. -QWERTY full keyboard designed, convenient for different measurement application scenarios. -Quick charge with internal lithium battery to improve efficiency under long time job. - Android 11.0 operating system equipped to maintain the productivity of numerous survey projects and data.

Product Parameters

• 8mmH/ 15mmV Real-time Kinematic Precision
• GPS, GLONASS, Galileo, BDS, QZSS, SBAS, IRNSS Signal Tracking
• 8 mm +0.7 mm / ° Tilt Survey Performance
• 1408/800+ Channels
• Support Multi-protocol Radio (Receive & Transmit)

iRTK5 GNSS RTK System (Base)

Benefiting from the next-generation GNSS engine, unlimited communication technology and innovative designs, iRTK5, the high-quality scalable GNSS receiver, provides an industry-leading GNSS RTK surveying solution.

Hi-RTP Global PPP Service

Edit

The correction source has been extended by Hi-RTP global correction service provided by Hi-Target. Enabling users to work without a base-station in rural or remote areas anywhere in the world.

HD Touchable OLED Screen

Edit

The newly designed HD OLED screen, which has RGB color and is touchable, has 1.3″ and 240*240 resolutions. Users can quickly check and set the receiver status for easier fieldwork.

Revolutionary Tilt Survey with Built-in IMU

Edit

Customers benefit from calibration-free for tilt surveys without centering. Once you reach the surveying points, immediately start the operation. Compared with bubble leveling, boost working efficiency by 20%.

Product Parameters

• 8 mm H/ 15 mm V Real-time kinematic precision
• GPS, GLONASS, Galileo, BDS, QZSS, SBAS signal tracking
• PPP Service
• 1404/800+ Channels
• Support multi-protocol radio (Receive & Transit)
• Revolutionary Tilt Survey with built-in IMU

Included in the bundle

• V200 GNSS RTK System (Rover) x 1
• iRTK5 GNSS RTK System (Base) x 1
• Power Adapter x 1
• USB Data Cable x 1
• TB-1 Antenna Connector x 1
• Survey Benchmark x 2
• Steel Tape (3Meters) x 1
• Short Connecting Rod x 1
• Radio Receiving Antenna x 1
• External Radio HDL460A(Hi-target) x 1
• Radio Communication Cable x 1
• Power Cable For External Radio x 1
• Extension Rod x 1
• Extension Rod Accessories Package x 1
• UHF-460C Transmitting Antenna x 1
• RF-35A Transmitting Antenna Connector x 1
• Tribrach Aluminum Sheet x 2
• Certificate Of Quality x 2
• Warranty Card x 2
• QR Code Manual Card (Hi-target) x 1
• Envelope x 2
• Plastic Case PVC Label (Hi-Target) x 2
• Base Plastic Case gray (137) w/o logo x 2
• Aluminum Tripod x 2
• Tribrach With Optical Plummet x 1
• Radio Receiving Antenna x 1
• Survey Pole Hi-target (new logo) 2.2m x 1
• Power Adapter x 1
• ihand55 Hand-held Controller x 1
• USB Data Cable x 2
• iHand55 Controller Pallet x 1
• Touch Pen x 1
• Carbon Fiber Bipod for Survey Pole x 1
